LC/APC Fiber Optic Male to Female Attenuators 1-25dB

Item
LC/APC attenuator
Description
Fiber Optic Attenuator is used in a wide variety of applications and can satisfy almost any requirement where a reduction in power is needed.
Collect
Details

Fiber Optical Attenuator is an electronic device that reduces the amplitude of an electronic signal.

multimode Single mode LC APC 1db, 5db, 10db,15dbfiber attenuator


Feature:                                                                                     Application:

Height Reliability And Stability                                                   Optical Fiber Communication Network

Durability (well over 100mw)                                                      Passive optical networks

Simple and Reliable structure                                                    Data Transmission Network

                                                                                                   CATV Fiber Optic Sensor

                                                                                                   Local Area Networks(LANs)

                                                                                                   Optic Instrumentation



Specifications

Operation wavelength

SM: 1200 to 1600nm or 1310/1550nm, MM: 850nm, 1300nm

Return Loss

≥ 55 db (UPC),  ≥ 65 db (APC)

Attenuation Accuracy

+/-0.5 db for 1 to 5db attenuation

+/-10% for 6 to 30db attenuation

Polarization Dependent loss

≤ 0.2db

Maximum optical Input power

200mW

Operating Temp Range

-40 to + 80 degree
