outdoor/indoor SMC 144 optic fiber distribution cross connection ODF DDF cabinet

outdoor/indoor SMC 144 optic fiber distribution cross connection ODF DDF cabinet

Features

l 1. Standard case body, made of high intensity, anti-corrosive, anti-aging special composite material(SMC), adapting various bad weather condition, with reliable sealing, water-proof and damp proof.

l 2. Single/double door. And protection level: IP65

l 3. Good design for inner structure, easy installation.

l 4. Clear indication of splicing and distribution.

l 5. The adapter can be ST, FC, SC etc.

l 6. Enough storage space inside.

l 7. Reliable cable fixation device and grounding device.

l 8. Good design of splicing routing and guarantee bending radius of fiber optic.

l  Environmental Temperature: -40oC~+60oC

l  Relative Humidity: :≤95% (+40oC)

l  Atmosphere pressure: 70Kpa – 106Kpa

l  Operating wavelength:1260 ~1650NM

l  Connector Loss (included repeatability and exchangeability ): ≤0.50dB

l  Insertion loss: ≤0.20dB.

l  Return loss: PC≥45.0dB ,UPC≥50.0dB,APC≥60.0dB

l  Insulating resistance: ≥2×104MΩ/500V (DC)

l  Voltage-resistance strength:≥3000V(DC),1 min no puncture, no arc-over.

l  Static loading-bearing capacity: the cover ≥980N, the side surface≥980N, the door hinge ≥200N
