24 port ODF Rack Mount Patch Panel with ST pigtails

Item
24 Core ODF full with ST
Description
optical distribution frame (ODF) is a frame used to provide cable interconnections between communication facilities, which can integrate fibre splicing, fibre termination, fibre optic adapters & connectors and cable connections together in a single unit. It can also work as a protective device to protect fibre optic connections from damage.
Collect
Details

24 port ODF Rack Mount Patch Panel with ST pigtails

Features:
1) Standard size, light weight and reasonable structure
2) Splice tray inside changeable
3) Can be used in 19'', 23'' standard distribution frame
4) Suitable for ribbon and single fiber
5) Various panel plate to fit different adapter interface
6) Front mark on the plate is easy for identification and operation
7) 24C, 36C, 48C, 72C 96C optional, with or without fiber optic pigtails and adapters
8) Easy for management and operation


Application:
1) Telecommunications subscriber loop
2) Fiber to the home (FTTH)
3) LAN/WAN
4) CATV


Specifications


Operating temperature

-5°C +40°C

Relative humidity

≤90% (when the temperature is below 30°C)

Atmosphere pressure

70Kpa – 106Kpa

Storage temperature

-40°C - +70°C

Insertion loss

≤0.20dB

Return loss

PC≥45dB ,UPC≥50dB,APC≥60dB

Durability

>1000times

Insulating resistance

≥1000 MΩ  500V

Voltage-resistance strength

Under the effect of 3000V, 1min, non-puncture, and no arc-over

Wavelength

850nm, 1310nm, 1550nm
