1U 2U, 24 PORT high density fiber optic metal terminal box with adpters

Description: Fiber optic patch panel is also called as fiber optic terminal box, fiber distribution panel. It is a hardware to terminate fiber optic cable or store cable.

Collect

Feature:

Made of cold-rolling steel, static spreading-plastic

FC/SC/ST/Others Adapters for Option, available.

Thickness: 0.7-1.3mm steel sheet

Sliding design or fixed desing

Light structure and fine-looking appearance.

Application:

CATV networks

Local area networks

Widely used in FTTH network

Data communications networks

Specifications

Operating temperature	-25°C +40°C
Relative humidity	≤90% (when the temperature is below 30°C)
Atmosphere pressure	70Kpa – 106Kpa
Storage temperature	-40°C - +70°C
Insertion loss	≤0.20dB
Return loss	PC≥45dB ,UPC≥50dB,APC≥60dB
Adapter	FC, SC. ST, LC
Insulating resistance	≥1000 MΩ 500V
Material	Cold-rolled sheet + Surface electrostatic spraying
Fiber port	4, 8 12,24,48 etc.
