FTTH Outdoor 19 inch 12 Fiber Optic ODF Equipment Rack Wall Mount Patch Panel Terminal Box

Description: n Fiber optic patch panel is also called as fiber optic terminal box, fiber distribution panel. It is a hardware to terminate fiber optic cable or store cable.

Collect

Feature:

Made of cold-rolling steel, static spreading-plastic

FC/SC/ST/Others Adapters for Option, available.

Thickness: 0.7-1.3mm steel sheet

Sliding design or fixed desing

Light structure and fine-looking appearance.

Application:

CATV networks

Local area networks

Widely used in FTTH network

Data communications networks

Specifications

Operating temperature	-5°C +40°C
Relative humidity	≤90% (when the temperature is below 30°C)
Atmosphere pressure	70Kpa – 106Kpa
Storage temperature	-40°C - +70°C
Insertion loss	≤0.20dB
Return loss	PC≥45dB ,UPC≥50dB,APC≥60dB
Durability	>1000times
Insulating resistance	≥1000 MΩ 500V
Voltage-resistance strength	Under the effect of 3000V, 1min, non-puncture, and no arc-over
Wavelength	850nm, 1310nm, 1550nm
